Brand Values Dial
Three brand values arranged around a rotating logo hub, advancing on a timer that is drawn rather than counted.
Our values
Palette · 03 tones
Our Colors, Our Values.
Three colors, three commitments. Each tone in the Argonaut palette represents a way we design, deliver, and partner.
Argonaut Red
Innovation
We turn complex MEP, HVAC, and fire safety requirements into clear, buildable routes from concept to commissioning.
01 / 03
Three reading orders have to be reconciled inside this component, because the desktop layout, the artwork's arms and the counter all number the values differently. The source comments on that, and on why the easing curve is hand-written rather than one of the CSS keywords, are worth more than the animation itself.
Features
- The active pill is the countdown: a fill sweeps across it over one interval and the end of that animation is what advances the carousel, so the indicator and the rotation cannot drift apart.
- The hub's rotation is cumulative rather than modular, so every selection sweeps forward through 120 degrees instead of snapping backwards.
- Arrival is accented with light rather than scale, through a Web Animations API pass that runs without remounting the in-flight spin.
- Autoplay pauses when the section leaves the screen, when the tab is hidden, and when the window loses focus, each tracked separately from a deliberate press of the pause control.
Usage
import { BrandValuesDial } from "@/components/showcase/brand-values-dial/brand-values-dial";
<BrandValuesDial />Source
The files this component is made of, as they run above. Copy them in, or take the whole page as markdown from the toolbar.
brand-values-dial.tsx
"use client";
import Image from "next/image";
import {
memo,
useCallback,
useEffect,
useRef,
useState,
type CSSProperties,
} from "react";
import { cn } from "@/lib/utils";
import logoLarge from "./logo-large.webp";
import styles from "./brand-values-dial.module.css";
const LOGO_KNOBS = {
sizePct: 238,
offsetXPct: 1,
offsetYPct: 32,
// 67° puts the Deep Marine arm in the visible window (red sits at -53°,
// green at 187°). The display order marine → red → green runs against the
// artwork's arm arrangement, so each step sweeps -120° (counterclockwise).
baseRotationDeg: 67,
rotationStepMultiplier: -1,
transitionMs: 900,
opacity: 1,
} as const;
// Strong ease-in-out, Emil's recommendation for elements moving between
// fixed positions. Built-in CSS easings are too weak for this kind of motion.
const ROTATION_EASE = "cubic-bezier(0.77, 0, 0.175, 1)";
type ValueItem = {
title: string;
colorName: string;
hex: string;
description: string;
};
const VALUES: ValueItem[] = [
{
title: "Reliability",
colorName: "Deep Marine",
hex: "#082B3A",
description:
"Clients rely on us when timing, coordination, and technical follow-through have to stay steady under real project pressure.",
},
{
title: "Innovation",
colorName: "Argonaut Red",
hex: "#942429",
description:
"We turn complex MEP, HVAC, and fire safety requirements into clear, buildable routes from concept to commissioning.",
},
{
title: "Sustainability",
colorName: "Systems Green",
hex: "#3B7A57",
description:
"We look for solutions that improve performance, reduce waste, and keep long-term operation in view from the first specification.",
},
];
// Maps display position to VALUES array index to show: Innovation (left), Reliability (right), Sustainability (top)
const DISPLAY_ORDER = [2, 1, 0];
// Values pre-ordered by display position. Derived from module constants, so it
// never changes: hoisted out of the render path rather than rebuilt per render.
const DISPLAY_VALUES = DISPLAY_ORDER.map((i) => VALUES[i]);
// Linear reading order for the mobile pill row, expressed as display indices.
// Desktop reads left → top → right = Innovation → Sustainability → Reliability,
// so mobile must follow the same sequence rather than the raw display order.
const MOBILE_PILL_ORDER = [1, 0, 2];
// Counter numbering follows the label reading order (Innovation, Sustainability,
// Reliability) as VALUES indices, independent of array or display order.
const NUMBER_ORDER = [1, 2, 0];
const getDisplayIndex = (valuesIndex: number) =>
DISPLAY_ORDER.indexOf(valuesIndex);
const getValuesIndex = (displayIndex: number) => DISPLAY_ORDER[displayIndex];
const AUTOPLAY_MS = 9000;
export function BrandValuesDial({ className }: { className?: string } = {}) {
// Track a cumulative step count so the logo's rotation always increases:
// every selection sweeps forward to the next state instead of snapping back.
// Starts at 1 so the reading order begins on Innovation (VALUES[1]); each
// step then advances Innovation → Sustainability → Reliability.
const [step, setStep] = useState(1);
// Off-screen / hidden-tab pause and the explicit user pause are tracked
// separately, matching the Strategic Partnerships carousel: autoplay only
// runs when the section is visible and the user hasn't paused it. Defaults to
// paused so the section stays inactive until the observer confirms it's shown.
const [autoPaused, setAutoPaused] = useState(true);
const [userPaused, setUserPaused] = useState(false);
const paused = autoPaused || userPaused;
const containerRef = useRef<HTMLDivElement>(null);
const currentValuesIndex =
((step % VALUES.length) + VALUES.length) % VALUES.length;
const currentDisplayIndex = getDisplayIndex(currentValuesIndex);
const active = VALUES[currentValuesIndex];
// Pause autoplay while the section is off-screen, the tab is hidden, or the
// window is not focused so the timer never runs in the background.
useEffect(() => {
const el = containerRef.current;
if (!el) return;
let onScreen = false;
const sync = () =>
setAutoPaused(!onScreen || document.hidden || !document.hasFocus());
const observer = new IntersectionObserver(
([entry]) => {
onScreen = entry.isIntersecting;
sync();
},
{ threshold: 0 },
);
observer.observe(el);
window.addEventListener("focus", sync);
window.addEventListener("blur", sync);
document.addEventListener("visibilitychange", sync);
sync();
return () => {
observer.disconnect();
window.removeEventListener("focus", sync);
window.removeEventListener("blur", sync);
document.removeEventListener("visibilitychange", sync);
};
}, []);
// Advance once the timer bar finishes a cycle. Driving the advance off the
// bar's animation keeps the indicator and the rotation in lockstep, and a
// manual selection remounts the bar (keyed on step) so the countdown always
// restarts from full rather than firing a stale pending tick.
const handleCycleComplete = useCallback(() => {
setStep((prev) => prev + 1);
}, []);
const handleSelect = useCallback((displayIndex: number) => {
setStep((prev) => {
const currentIdx =
((prev % VALUES.length) + VALUES.length) % VALUES.length;
const targetValuesIdx = getValuesIndex(displayIndex);
if (currentIdx === targetValuesIdx) return prev;
const offset =
(targetValuesIdx - currentIdx + VALUES.length) % VALUES.length;
return prev + offset;
});
}, []);
const togglePause = useCallback(() => setUserPaused((value) => !value), []);
return (
<section
className={cn(
styles.root,
"relative overflow-hidden bg-white py-12 text-[var(--brand-ink)] lg:py-16",
className,
)}
>
<div
ref={containerRef}
className="mx-auto flex w-full max-w-[80rem] flex-col gap-8 px-6 sm:gap-9 md:px-8 lg:gap-10"
>
<div className="grid grid-cols-1 items-baseline gap-x-8 gap-y-2 lg:grid-cols-12">
<div className="col-span-1 flex items-baseline gap-x-4 lg:col-span-3 lg:flex-col lg:border-r lg:border-[var(--brand-line)] lg:pr-6">
<p className="text-xs leading-[1.5] font-bold tracking-[0.22em] text-[var(--brand-blue)] uppercase">
Our values
</p>
<p className="font-mono text-xs leading-[1.5] text-[var(--brand-steel)] lg:mt-2">
Palette · 03 tones
</p>
</div>
<div className="col-span-1 lg:col-span-9">
<h2 className="text-[2rem] leading-[1.08] font-semibold tracking-[-0.035em] text-[var(--brand-ink)] sm:text-[2.5rem] lg:text-[3.157rem]">
Our Colors, Our Values.
</h2>
<p className="mt-2 max-w-3xl text-base leading-[1.55] font-medium tracking-[-0.01em] text-[var(--brand-steel)]">
Three colors, three commitments. Each tone in the Argonaut palette
represents a way we design, deliver, and partner.
</p>
</div>
</div>
<ValueDiagram
active={active}
currentDisplayIndex={currentDisplayIndex}
step={step}
paused={paused}
onSelect={handleSelect}
onCycleComplete={handleCycleComplete}
/>
<div className="flex flex-col items-center gap-5">
<ActiveValueStack currentDisplayIndex={currentDisplayIndex} />
<PlaybackControls
counter={NUMBER_ORDER.indexOf(currentValuesIndex) + 1}
total={VALUES.length}
userPaused={userPaused}
onTogglePause={togglePause}
/>
</div>
</div>
</section>
);
}
// Inlined rather than pulled from an icon package: the showcase build ships no
// icon dependency, and these two glyphs are the whole requirement.
function PlayGlyph(props: { className?: string }) {
return (
<svg
viewBox="0 0 24 24"
fill="currentColor"
aria-hidden="true"
className={props.className}
>
<polygon points="6 3 20 12 6 21 6 3" />
</svg>
);
}
function PauseGlyph(props: { className?: string }) {
return (
<svg
viewBox="0 0 24 24"
fill="currentColor"
aria-hidden="true"
className={props.className}
>
<rect x="6" y="4" width="4" height="16" rx="1" />
<rect x="14" y="4" width="4" height="16" rx="1" />
</svg>
);
}
const PlaybackControls = memo(function PlaybackControls({
counter,
total,
userPaused,
onTogglePause,
}: {
counter: number;
total: number;
userPaused: boolean;
onTogglePause: () => void;
}) {
const number = String(counter).padStart(2, "0");
const count = String(total).padStart(2, "0");
// The timer indicator itself lives on the logo's border (see CenterPill);
// these controls only pause/resume the rotation and report the position.
return (
<div className="mx-auto flex items-center gap-4">
<button
type="button"
onClick={onTogglePause}
aria-label={
userPaused ? "Resume values rotation" : "Pause values rotation"
}
aria-pressed={userPaused}
className="flex h-9 w-9 shrink-0 cursor-pointer items-center justify-center rounded-full border border-[var(--brand-line)] text-[var(--brand-ink)] transition-colors duration-200 hover:bg-[var(--brand-mist)] focus-visible:ring-2 focus-visible:ring-[var(--brand-blue)]/40 focus-visible:ring-offset-2 focus-visible:outline-none"
>
{userPaused ? (
<PlayGlyph className="h-3.5 w-3.5" />
) : (
<PauseGlyph className="h-3.5 w-3.5" />
)}
</button>
<p className="font-mono text-xs leading-[1.5] tabular-nums text-[var(--brand-steel)]">
{number} / {count}
</p>
</div>
);
});
const ValueDiagram = memo(function ValueDiagram({
active,
currentDisplayIndex,
step,
paused,
onSelect,
onCycleComplete,
}: {
active: ValueItem;
currentDisplayIndex: number;
step: number;
paused: boolean;
onSelect: (displayIndex: number) => void;
onCycleComplete: () => void;
}) {
const [top, left, right] = DISPLAY_VALUES;
return (
<div className="mx-auto w-full">
{/* Desktop / tablet: hub-and-spoke layout */}
<div className="hidden sm:grid sm:grid-cols-[minmax(0,1fr)_auto_minmax(0,1fr)] sm:grid-rows-[auto_auto] sm:items-center sm:justify-items-center">
{/* Row 1: empty | top satellite + connector | empty */}
<div aria-hidden="true" />
<div className="flex flex-col items-center">
<SatellitePill
value={top}
isActive={currentDisplayIndex === 0}
step={step}
paused={paused}
onSelect={() => onSelect(0)}
onCycleComplete={onCycleComplete}
/>
<Connector orientation="vertical" />
</div>
<div aria-hidden="true" />
{/* Row 2: left satellite + connector | center pill | connector + right satellite */}
<div className="flex w-full items-center justify-end">
<SatellitePill
value={left}
isActive={currentDisplayIndex === 1}
step={step}
paused={paused}
onSelect={() => onSelect(1)}
onCycleComplete={onCycleComplete}
/>
<Connector orientation="horizontal" />
</div>
<CenterPill activeHex={active.hex} step={step} />
<div className="flex w-full items-center justify-start">
<Connector orientation="horizontal" />
<SatellitePill
value={right}
isActive={currentDisplayIndex === 2}
step={step}
paused={paused}
onSelect={() => onSelect(2)}
onCycleComplete={onCycleComplete}
/>
</div>
</div>
{/* Mobile: stacked center pill with pills row underneath. Pills follow the
desktop left → top → right reading order (Innovation, Sustainability,
Reliability) rather than the raw display order. */}
<div className="flex flex-col items-center gap-6 sm:hidden">
<CenterPill activeHex={active.hex} step={step} />
<div className="flex flex-wrap items-center justify-center gap-2">
{MOBILE_PILL_ORDER.map((displayIndex) => {
const value = DISPLAY_VALUES[displayIndex];
return (
<SatellitePill
key={value.title}
value={value}
isActive={currentDisplayIndex === displayIndex}
step={step}
paused={paused}
onSelect={() => onSelect(displayIndex)}
onCycleComplete={onCycleComplete}
/>
);
})}
</div>
</div>
</div>
);
});
const CenterPill = memo(function CenterPill({
activeHex,
step,
}: {
activeHex: string;
step: number;
}) {
const stepDeg = (360 / VALUES.length) * LOGO_KNOBS.rotationStepMultiplier;
// Cumulative: never resets, always sweeps in one consistent direction.
const rotation = LOGO_KNOBS.baseRotationDeg + step * stepDeg;
const tx = -50 + LOGO_KNOBS.offsetXPct;
const ty = -50 + LOGO_KNOBS.offsetYPct;
// Arrival accent: when the value changes, the hub catches the light, its glow
// swells and settles in the value's colour while the logo briefly brightens
// and deepens, peaking as the spin lands. Light, not scale, to stay premium.
// Run via the Web Animations API rather than a keyed remount so the rotating
// logo (and its in-flight spin transition) is never torn down. Skipped on
// first mount and under reduced motion.
const pillRef = useRef<HTMLDivElement>(null);
const logoRef = useRef<HTMLDivElement>(null);
const firstRun = useRef(true);
useEffect(() => {
if (firstRun.current) {
firstRun.current = false;
return;
}
const pill = pillRef.current;
const logo = logoRef.current;
if (!pill || !logo) return;
if (window.matchMedia("(prefers-reduced-motion: reduce)").matches) return;
const duration = 820;
const easing = "cubic-bezier(0.23, 1, 0.32, 1)";
const resting = `0 0 80px -10px ${activeHex}66, 0 30px 60px -30px rgba(6,23,34,0.25)`;
const peak = `0 0 120px -2px ${activeHex}cc, 0 30px 60px -30px rgba(6,23,34,0.25)`;
const glow = pill.animate(
[
{ boxShadow: resting, offset: 0 },
{ boxShadow: peak, offset: 0.72 },
{ boxShadow: resting, offset: 1 },
],
{ duration, easing },
);
const light = logo.animate(
[
{ filter: "brightness(1) saturate(1)", offset: 0 },
{ filter: "brightness(1.14) saturate(1.18)", offset: 0.72 },
{ filter: "brightness(1) saturate(1)", offset: 1 },
],
{ duration, easing },
);
return () => {
glow.cancel();
light.cancel();
};
}, [step, activeHex]);
return (
<div className="relative flex items-center justify-center">
<span
aria-hidden="true"
className="pointer-events-none absolute -inset-2 rounded-full border border-[var(--brand-line)]/60 sm:-inset-3"
/>
<span
aria-hidden="true"
className="pointer-events-none absolute -inset-4 rounded-full border border-[var(--brand-line)]/35 sm:-inset-6"
/>
<span
aria-hidden="true"
className="pointer-events-none absolute -inset-7 rounded-full border border-[var(--brand-line)]/20 sm:-inset-10"
/>
<div
ref={pillRef}
className="relative flex h-28 w-60 items-center justify-center overflow-hidden rounded-full border border-[var(--brand-line)] transition-[background-color,box-shadow] duration-700 ease-[cubic-bezier(0.23,1,0.32,1)] motion-reduce:transition-none sm:h-32 sm:w-80 lg:h-36 lg:w-96"
style={{
backgroundColor: `${activeHex}33`,
boxShadow: `0 0 80px -10px ${activeHex}66, 0 30px 60px -30px rgba(6,23,34,0.25)`,
}}
>
<div
ref={logoRef}
aria-hidden="true"
className="pointer-events-none absolute top-1/2 left-1/2 aspect-square motion-reduce:transition-none"
style={{
height: `${LOGO_KNOBS.sizePct}%`,
opacity: LOGO_KNOBS.opacity,
transform: `translate(${tx}%, ${ty}%) rotate(${rotation}deg)`,
transitionProperty: "transform",
transitionDuration: `${LOGO_KNOBS.transitionMs}ms`,
transitionTimingFunction: ROTATION_EASE,
}}
>
<Image
src={logoLarge}
alt=""
fill
sizes="(min-width: 1024px) 700px, (min-width: 640px) 600px, 500px"
className="object-contain"
priority={false}
/>
</div>
</div>
</div>
);
});
const SatellitePill = memo(function SatellitePill({
value,
isActive,
step,
paused,
onSelect,
onCycleComplete,
}: {
value: ValueItem;
isActive: boolean;
step: number;
paused: boolean;
onSelect: () => void;
onCycleComplete: () => void;
}) {
// --pill-color is the single source for the fill, the track tint, and the
// hover affordances, so each pill previews its own value. When active, the
// pill doubles as the timer: a colour fill sweeps left-to-right over one
// interval, then onAnimationEnd advances. The unfilled track is a light tint
// (ink label); the fill overlay carries the full colour (white label), keyed
// on step so a manual selection restarts the countdown.
// Hover idiom borrowed from .about-cta-button, a deepening fill with a slow,
// luxurious ease, made grander with a soft double-ring halo that radiates
// outward. No lift; the halo (box-shadow) clears the pill's overflow-hidden.
const base =
"group relative inline-flex h-10 cursor-pointer items-center justify-center overflow-hidden rounded-full px-4 text-sm font-medium tracking-[-0.005em] transition-all duration-300 ease-[cubic-bezier(0.2,0,0,1)] focus-visible:outline focus-visible:outline-2 focus-visible:outline-offset-2 focus-visible:outline-[var(--brand-blue)] motion-reduce:transition-none sm:px-5";
const stateClass = isActive
? "bg-[color-mix(in_srgb,var(--pill-color)_18%,var(--brand-mist))] text-[var(--brand-ink)] hover:shadow-[0_0_0_4px_color-mix(in_srgb,var(--pill-color)_35%,transparent),0_0_0_11px_color-mix(in_srgb,var(--pill-color)_14%,transparent)]"
: "bg-[var(--brand-mist)] text-[var(--brand-ink)] hover:bg-[color-mix(in_srgb,var(--brand-ink)_10%,var(--brand-mist))] hover:shadow-[0_0_0_4px_color-mix(in_srgb,var(--brand-ink)_9%,transparent),0_0_0_11px_color-mix(in_srgb,var(--brand-ink)_4%,transparent)]";
return (
<button
type="button"
onClick={onSelect}
aria-pressed={isActive}
aria-label={`Show ${value.title}`}
className={`${base} ${stateClass}`}
style={{ "--pill-color": value.hex } as CSSProperties}
>
<span className="whitespace-nowrap">{value.title}</span>
{isActive ? (
<span
key={step}
aria-hidden="true"
onAnimationEnd={onCycleComplete}
style={{
animationDuration: `${AUTOPLAY_MS}ms`,
animationPlayState: paused ? "paused" : "running",
}}
className={cn(
styles.pillFill,
"absolute inset-0 flex items-center justify-center bg-[var(--pill-color)] px-4 text-white sm:px-5",
)}
>
<span className="whitespace-nowrap">{value.title}</span>
</span>
) : null}
</button>
);
});
const Connector = memo(function Connector({
orientation,
}: {
orientation: "vertical" | "horizontal";
}) {
if (orientation === "vertical") {
return (
<span
aria-hidden="true"
className="my-2 block h-10 w-px bg-[var(--brand-line)] lg:h-14"
/>
);
}
return (
<span
aria-hidden="true"
className="mx-2 block h-px w-12 bg-[var(--brand-line)] sm:w-16 lg:w-24"
/>
);
});
const ActiveValueStack = memo(function ActiveValueStack({
currentDisplayIndex,
}: {
currentDisplayIndex: number;
}) {
return (
<div className="mx-auto grid">
{DISPLAY_VALUES.map((value, index) => {
const isActive = index === currentDisplayIndex;
return (
<div
key={value.title}
className={`flex flex-col items-center text-center transition-[opacity,filter] duration-500 ease-[cubic-bezier(0.23,1,0.32,1)] [grid-area:1/1] motion-reduce:transition-none ${
isActive
? "opacity-100 blur-[0px]"
: "pointer-events-none opacity-0 blur-[6px]"
}`}
aria-hidden={!isActive}
>
<div className="flex items-center gap-3">
<span
aria-hidden="true"
className="block h-2.5 w-2.5 rounded-full"
style={{ backgroundColor: value.hex }}
/>
<p
className="text-xs leading-[1.5] font-bold tracking-[0.22em] uppercase"
style={{ color: value.hex }}
>
{value.colorName}
</p>
</div>
<h3 className="mt-3 text-[2rem] leading-[1.08] font-semibold tracking-[-0.04em] text-balance text-[var(--brand-ink)] sm:text-[2.5rem] lg:text-[3.157rem]">
{value.title}
</h3>
<p className="mt-3 max-w-xl text-base leading-[1.55] font-medium tracking-[-0.01em] text-pretty text-[var(--brand-steel)]">
{value.description}
</p>
</div>
);
})}
</div>
);
});brand-values-dial.module.css
/* The component carries its own brand tokens. In the source app these live in
the global stylesheet; here they are scoped to the root so the showcase can
be dropped into any page without the host defining anything. */
.root {
--brand-ink: #061722;
--brand-marine: #082b3a;
--brand-mist: #eef3f1;
--brand-steel: #5f7077;
--brand-line: rgba(6, 23, 34, 0.13);
--brand-blue: #087ea4;
}
/* Timer fill for the active pill: the value's colour sweeps left-to-right
across the pill over one interval, acting as the countdown. The leading edge
is masked to the pill shape by overflow-hidden. */
@keyframes pill-fill {
from {
clip-path: inset(0 100% 0 0);
}
to {
clip-path: inset(0 0 0 0);
}
}
.pillFill {
/* Duration is overridden inline from AUTOPLAY_MS; keep in sync. */
animation: pill-fill 5000ms linear both;
}
@media (prefers-reduced-motion: reduce) {
.pillFill {
animation: none;
clip-path: inset(0 0 0 0);
}
}
